# Class 8 RD Sharma Solutions – Chapter 27 Introduction to Graphs – Exercise 27.2

**Question 1. The following table shows the number of patients discharged from a hospital with HIV diagnosis in different years:**

Years | 2002 | 2003 | 2004 | 2005 | 2006 |

Number of Patients | 150 | 170 | 195 | 225 | 230 |

**Represent the information by a graph.**

**Solution:**

Attention reader! All those who say programming isn't for kids, just haven't met the right mentors yet. Join the ** Demo Class for First Step to Coding Course, **specifically **designed for students of class 8 to 12. **

The students will get to learn more about the world of programming in these **free classes** which will definitely help them in making a wise career choice in the future.

From the question as we know that,

The number of patients – is a dependent variable.

Year – is an independent variable.

Take years on x-axis

and Number of patients on y – axis

Choose the following scale:

X – axis: 2 cm = 1 year

Y – axis: 1 cm = 10 patients

Consider that on the x-axis, origin (O) represents 2001 and on the y-axis, origin (O) represents 120,

i.e. O (2001, 120).

Now, Plot

(2002, 150),

(2003, 170),

(2004, 195),

(2005, 225),

(2006, 230).

Join these points in the following graph as shown below.

**Question 2. The following table shows the amount of rice grown by a farmer in different years:**

Years | 2000 | 2001 | 2002 | 2003 | 2004 | 2005 | 2006 |

Rice grown (in quintals) | 200 | 180 | 240 | 260 | 250 | 200 | 270 |

**Plot a graph to illustrate this information.**

**Solution:**

From the question as we know that,

Year – is an independent variable

Quantity of rice grown is a dependent variable.

So, take

Year on X – axis

Quantity of rice grown on Y – axis

Choose following scale:

X – axis: 2 cm = 1 year

Y – axis: 1 cm = 20 quintals

Consider that the origin O represents the coordinates (1999, 160).

i.e. O (1999,160)

Now, Plot

(2000, 200),

(2001, 180),

(2002, 240),

(2003, 260),

(2004, 250),

(2005, 200),

(2006, 270).

Join these points on the following graph as shown below:

**Question 3.** **The following table gives the information regarding the number of persons employed to a piece of work and time taken to complete the work:**

Number of persons | 2 | 4 | 6 | 8 |

Time taken (in days) | 12 | 6 | 4 | 3 |

**Plot the graph of this information.**

**Solution:**

From the question as we know that,

The number of persons – is an independent variable

Time taken – is a dependent variable.

So, take

The number of persons on the X – axis

Time taken on the Y – axis.

Choose following scale:

X – axis: 2 cm = 2 persons

Y – axis: 2 cm = 2 days

Now, plot

(2, 12),

(4, 6),

(6, 4),

(8, 3).

Join these points on the following graph as shown below:

**Question 4. The following table gives the information regarding length of a side of a square and its area**

Length of a side (in cm) | 1 | 2 | 3 | 4 | 5 |

Area of square (in cm^{2}) | 1 | 4 | 9 | 16 | 25 |

**Draw a graph to illustrate this information.**

**Solution:**

From the question as we know that,

Length of a side – is an independent variable

Area of the square – is a dependent variable.

So, take

Length of a side on the X – axis

Area of the square on the Y – axis.

Choose following scale:

X – axis: 2 cm = 1 cm

Y – axis: 1 cm = 2 cm

^{2}Now, plot

(1, 1),

(2, 4),

(3, 9),

(4, 16),

(5, 25).

Join these points in the following graph as shown below:

**Question 5. The following table shows the sales of a commodity during the years 2000 to 2006.**

Years | 2000 | 2001 | 2002 | 2003 | 2004 | 2005 | 2006 |

Sales (in lakhs of Rs) | 1.5 | 1.8 | 2.4 | 3.2 | 5.4 | 7.8 | 8.6 |

**Draw a graph of this information.**

**Solution:**

From the question as we know that,

Year – is an independent variable

Sales – is a dependent variable.

So, take

Year on the X – axis

Sales on the Y – axis.

Choose following scale:

X – axis: 2 cm = 1 year

Y – axis: 2 cm = 1 lakh rupees

Consider that on x-axis, origin (O) represents 1991.

Hence, the coordinates of O are (1991, 0).

Now, plot

(2000, 1.5),

(2001, 1.8),

(2002, 2.4),

(2003, 3.2),

(2004, 5.4),

(2005, 7.8)

(2006, 8.6).

Join these points on the following graph as shown below;

**Question 6. Draw the temperature-time graph in each of the following cases:**

**(i) **

Time (in hours) | 7:00 | 9:00 | 11:00 | 13:00 | 15:00 | 17:00 | 19:00 | 21:00 |

Temperature (in ^{o}F) | 100 | 101 | 104 | 102 | 100 | 99 | 100 | 98 |

**(ii)**

Time (in hours) | 8:00 | 10:00 | 12:00 | 14:00 | 16:00 | 18:00 | 20:00 |

Temperature (in ^{o}F) | 100 | 101 | 104 | 103 | 99 | 98 | 100 |

**Solution:**

(i)From the question as we know that,Time – is an independent variable

Temperature – is a dependent variable.

So, take

Time on the X – axis

Temperature on the Y – axis.

Choose following scale:

X – axis: 1 cm = 1 hour

Y – axis: 1 cm = 1°F

Consider that on the x-axis, the coordinate of origin is 6:00.

On y-axis, the coordinate of origin is 94°F.

Hence, the coordinates of 0 are (6:00, 94).

Now, plot

(7:00, 100),

(9:00, 101),

(11:00, 104)

(21:00, 98)

Join these points on the following graph as shown below:

(ii)From the question we know that,Time – is an independent variable

Temperature – is a dependent variable.

So, take

Time on the X – axis

Temperature on the Y – axis.

Choose following scale:

X – axis: 2 cm = 2 hours

Y – axis: 1 cm = 1°F

Consider that on the x-axis, the coordinate of origin is 6:00.

On y-axis, the coordinate of origin is 94°F.

Thus, the coordinates of 0 are (6:00, 94).

Now, plot

(8:00, 100),

(10:00, 101),

(12:00, 104)…..

(20:00, 100).

Join these points on the graph as shown below:

**Question 7. Draw the velocity-time graph from the following data:**

Time (in hours) | 7:00 | 8:00 | 9:00 | 10:00 | 11:00 | 12:00 | 13:00 | 14:00 |

Speed (in km/hr) | 30 | 45 | 60 | 50 | 70 | 50 | 40 | 45 |

**Solution:**

From the question as we know that,

Time – is an independent variable.

Speed – is a dependent variable.

So, take

Time on the X – axis

Speed on the Y – axis.

Choose following scale:

X – axis: 2 big division = 1 hour

Y – axis: 1 big division = 10 km/hr

Consider that on the x-axis, the coordinate of origin (O) is 7:00.

Thus, the coordinates of O are (7:00, 0).

Now, plot

(7:00, 30),

(8:00, 45),

(9:00, 60),

(10:00, 50),

(11:00, 70),

(12:00, 50),

(13:00, 40),

(14:00, 45).

Join these points on the graph as shown below:

**Question 8.** **The runs scored by a cricket team in first 15 overs are given below:**

Overs: | I | II | III | IV | V | VI | VII | VIII | IX | X | XI | XII | XIII | XIV | XV |

Runs: | 2 | 1 | 4 | 2 | 6 | 8 | 10 | 21 | 5 | 8 | 3 | 2 | 6 | 8 | 12 |

**Draw the graph representing the above data in two different ways as a graph and as a bar chart.**

**Solution:**

From the question as we know that,

Over – is an independent variable.

Run is a dependent variable.

So, take

Overs on the X – axis

Runs on the Y – axis.

Choose following scale:

X – axis: 1 cm = 1 over

Y – axis: 1 cm = 2 runs

Now, plot

(I, 2),

(II, 1),

(III, 4)…

(XV, 12).

Join these points on graph as shown below:

The bar graph is:

**Question 9. The runs scored by two teams A and B in first 10 overs are given below:**

Overs | I | II | III | IV | V | VI | VII | VIII | IX | X |

Team A | 2 | 1 | 8 | 9 | 4 | 5 | 6 | 10 | 6 | 2 |

Team B | 5 | 6 | 2 | 10 | 5 | 6 | 3 | 4 | 8 | 10 |

**Draw a graph depicting the data, making the graphs on the same axes in each case in two different ways as a graph and as a bar chart.**

**Solution:**

From the question as we know that,

Over – is an independent variable.

Run – is a dependent variable.

So, take

Overs on X – axis

Runs on the Y – axis.

Choose following scale:

X – axis: 1 cm = 1 over

Y – axis: 1 cm = 1 run

Now, plot

(I, 2),

(II, 1),

(III, 8)…

(X, 2) for team A

and

(I, 5),

(II, 6),

(III, 8) …..

(X, 10) for team B.

Join these points on graph as shown below:

The bar graph is:
